Home > Products > Bearing Brand > 32310 original koyo japan brand tapered roller bearings

32310 original koyo japan brand tapered roller bearings

Product Description

Product Description

32310 original koyo japan brand tapered roller bearings

A part of our products

Pictures show

Drawing

Related models and specifications

Bearing                                                                       Mass
No. d D T kg
31304 20 52 16.25 0.175
31305 25 62 18.25 0.26
31306 30 72 20.75 0.39
31307 35 80 22.75 0.52
31308 40 90 25.25 0.72
31309 45 100 27.25 0.95
31310 50 110 29.25 1.2
31311 55 120 31.5 1.55
31312 60 130 33.5 1.9
31313 65 140 36 2.35
31314 70 150 38 2.95
31315 75 160 40 3.5
31316 80 170 42.5 4.05
31317 85 180 44.5 4.6
31318 90 190 46.5 5.9
31319 95 200 49.5 6.95
31320 100 215 56.5 8.6
31321 105 225 58 9.65
31322 110 240 63 12
31324 120 260 68 15.3
31326 130 280 72 19.1
31328 140 300 77 23
31330 150 320 82 28



Description and application



Tapered Roller Bearing can be separated. It is a component , composed of inner ring , outer ring , rollers and cage . It can be installed separately. The contact line corrected for contact between the roller and the raceway reduces stress concentration. It can stand large radial loads and axial loads. As the tapered roller bearings can only send one-way axial load, it need another tapered roller bearing with a symmetrical mounting to send in the opposite direction of axial load.



Single Row Tapered Roller Bearing has an outer ring. Inner ring and a group of tapered roller are encased in a basket-shaped cage into an inner ring assembly. The outer ring can be separated from the inner ring assembly. According to the ISO standard of tapered roller bearing outer dimension specification, any standard type of inner and outer rings can be able to achieve international exchange with the outer ring or inner ring of the same models. Scilicet, in addition to the external dimensions, tolerances of outer ring in the same modles should comply with the regulations of ISO492GB307,the cone angle of the inner component and the diameter of component cone must also meet the relevant provisions of the swap.



Usually the cone Angle of outer ring raceway on single row tapered roller bearing is between 10°~19°,it can simultaneously stand the combined effect of bearing load and radial load. The greater the Angle,the more axial load can be bear. Big cone Angle bearings,end number to add B means the cone angle between 25 ° ~ 29 °. It can can withstand a large axial load.  In addition, the single row Taper Roller Bearings can adjust the clearance in the process of the device's size.



The inner or outer ring of double row Taper Roller Bearing is a whole. The small end of two inner (or outer) rings are similar. There is a spacer between two rings. The clearance is adjusted by the thickness of the spacer. The spacer can also be used to adjust the pre-surplus of double row tapered roller bearings.





35000 double row tapered roller bearings have a variety of internal structure:

-- with a spacer and a steel plate punched window-type cage

--  with a spacer , hollow roller and pillar steel cage



37000-type structure of double row tapered roller bearings have a variety of internal structure:

-- with a spacer, cage and steel plate.

-- with a spacer, hollow roller and steel pillar type cage.



Application

Tapered roller bearings are widely used in automobiles, rolling mills, mining, metallurgy, plastics machinery and other industries.



Single row taper roller is the most be used of the taper roller bearing series. The small sizes Double row taper roller are used in the car wheel hub in the recently years. Four-row taper roller bearings were used in large cold, hot rolling mill, and other heavy machinery.



Double row tapered roller bearings are mainly used for gear boxes, lifting equipment, rolling mills and for mining machinery, such as tunnel boring machine.

Regarding Taper Roller Bearing Application
1. Material handling machinery:mining machinery, textile machinery, lifting equipment, Agricultural machinery: tractors, harvesting machinery, etc.

2.Heavy-duty mining machinery: metallurgical machinery, mining machinery, lifting machinery, loading and unloading machinery, industrial vehicles, cement equipment, etc.

3. Construction Machinery: forklifts, earth moving machinery, compaction machinery, concrete machinery, etc.

4.The general petrochemical machinery: oil drilling machinery, oil refining machinery, chemical machinery, gas compressors, paper machinery, printing machinery, etc.

5.Machine tools: forging machinery, foundry machinery, woodworking machinery, etc.

6. Car: truck, road, bus, car, modified car, motorcycle, etc.
